main.cpp

/*
    ECE 4180 GATECH Fall 2016
    Boa-Lin Lai, Sameual Choi
*/
#include "mbed.h"
#include "Motor.h"
#include "ble.h"
#include <stdlib.h>
#include <algorithm>
DigitalOut myled1(LED1);
DigitalOut myled2(LED2);
DigitalOut myled3(LED3);
DigitalOut myled4(LED4);
AnalogIn wallSensor(p19);
AnalogIn edgeSensor(p20);
PwmOut speaker(p21);
Serial pc(USBTX, USBRX);
Motor ml(p23, p12, p11); // pwm, fwd, rev
Motor mr(p24, p14, p13); // pwm, fwd, rev
//Interrupt routine to parse message with one new character per serial RX interrupt
volatile bool isOn = false;
volatile bool edge = false;
volatile bool wall = false;
volatile double speed = 0.0;
volatile double wallDis = 0.0;
volatile double edgeDis = 0.0;
Ticker edge_detector;
Ticker wall_detector;

void edgeMove()
{
        ml.speed(-0.3);
        mr.speed(-0.3);
        for (int i=0; i<10; i=i+2) {
        speaker.period(1.0/969.0);
        speaker = float(i)/50.0;
        wait(.25);
        speaker.period(1.0/800.0);
        wait(.25);
    }
    edge = false;
    wall = false;
    speaker = 0;
     ml.speed(-0.5);
     mr.speed(0.5);
     wait(0.5);
}
void isEdge() {

    if(edgeDis > 2.5)
    {
         speed = 0;
         edge =  true;
    }
    else
    {
        edge = false;
    }
}

void isWall() {

    if(wallDis > 0.7)
    {
         speed = 0;
         wall = true;
    }
    else
    {
        wall = false;
    }
}


void BLE_action()
{
        if(button_ready && (bnum=='1')) { // button 4 changed
            if(isOn == true)
            {
              speed += 0.1;
              if(speed > 0.7) speed  = 0.7;
            }
            myled1 = bhit - '0'; //turn led4 on/off
            button_ready = 0; //reset flag after reading button message
        }
        else if(button_ready && (bnum=='2')) { // button 4 changed
            if(isOn == true)
            {
                speed -= 0.1;
                if(speed < 0.3 ) speed  = 0.3;
            }
            myled2 = bhit - '0'; //turn led4 on/off
            button_ready = 0; //reset flag after reading button message
        }
        else if(button_ready && (bnum=='3')) { // button 4 changed
            speed = 0;
            isOn = false;
            myled3 = bhit - '0'; //turn led4 on/off
            button_ready = 0; //reset flag after reading button message
        }
        else if(button_ready && (bnum=='4')) { // button 4 changed
            isOn = true;
            speed = 0.3;
            myled4 = bhit - '0'; //turn led4 on/off
            button_ready = 0; //reset flag after reading button message
        }



}
void print_speed()
{
    pc.printf("%-76s%0.2f\n",speed);
}
int main()
{
//attach interrupt function for each new Bluetooth serial character
    Blue.attach(&parse_message,Serial::RxIrq);
    edge_detector.attach(&isEdge, 0.02);
    wall_detector.attach(&isWall , 0.02);
    while(1) {
        //check for a new button message ready
        BLE_action();
        //do other tasks in main - interrupts will process button message characters
        myled4 = 1;
        wallDis = wallSensor;
        edgeDis = 1/edgeSensor;
        wait(0.05);
        myled4 = 0;
        wait(0.05);
        ml.speed(speed);
        mr.speed(pow(speed,0.2));
        if((edge == true) || (wall == true))
        {
            edgeMove();
        }
        //pc.printf("IR sensor reads %2.2f\n ", a);
        //pc.printf("\rDistance is %2.2f cm \n ", a);
        //pc.printf("%0.5f\n",dis);
    }
}
