#include "mbed.h"
#include "LinkedList_ll/linkedlist_ll.h"
#include "LEDCube/LEDCube.h"

Serial pc(USBTX, USBRX); // tx, rx
I2C my2c(p28, p27);
LEDcube myCube(my2c, p23, p22, p21, 0x40, 4);

void initializeSnake(LLRoot * master);
void resetSnake(LLRoot * master);
void moveSnake(void);
void generateFruit(LLRoot * master);
void printSnakeLayer(const LLRoot * master, char layer);
void printSnakeCube(const LLRoot * master);
void getSnakeInput(void);
void setSnakeFlag(void);

LLRoot Snake;
Ticker tick;
Timer  sysClock;

InterruptIn b_xpos(p5);
InterruptIn b_xneg(p6);
InterruptIn b_ypos(p7);
InterruptIn b_yneg(p8);
InterruptIn b_zpos(p9);
InterruptIn b_zneg(p10);

char key, reset;
char errcode = 0;
char snakeFlag = 0;
char moveFlag = 0;

int main() {

    sysClock.reset();
    sysClock.start();
    my2c.frequency(400000);

    b_xpos.fall(&getSnakeInput);
    b_xpos.mode(PullUp);
    b_xneg.fall(&getSnakeInput);
    b_xneg.mode(PullUp);
    b_ypos.fall(&getSnakeInput);
    b_ypos.mode(PullUp);
    b_yneg.fall(&getSnakeInput);
    b_yneg.mode(PullUp);
    b_zpos.fall(&getSnakeInput);
    b_zpos.mode(PullUp);
    b_zneg.fall(&getSnakeInput);
    b_zneg.mode(PullUp);
    wait(0.2);

    initializeSnake(&Snake); // sets ticker to SPEED

    if(LLDEBUG) printListLL(&Snake);
    while(1) {

        myCube.lightCube(CUBE_DELAY);
        if(snakeFlag) {
            snakeFlag = 0;
            moveSnake();
        }
    }

    //freeListLL(&Snake);
    //printf("$ Program complete ... how did we get here?\r\n");

}

void setSnakeFlag(void) {
    snakeFlag = 1;
}

void initializeSnake(LLRoot * master) {
    /* Start Snake at 3 in length
     * x, y, z:layer
     */

    //if(master != NULL)      // Uh oh, non-empty snake?
    //    freeListLL(master); // No matter

    initializeLL(master);
    __disable_irq();
    addToHeadLL(master, 0, 0, 0);
    __enable_irq();
    // BEAMMEUPSCOTTY
    myCube.plotPoint(0, 0, 0);
    master->direction = XPOS;
    //master->length = 1;

    generateFruit(master);

    // Note: What if fruit is generated on snake?
    // The user will not be able to see it until all snake nodes have gone
    // over it

    tick.attach(&setSnakeFlag, SPEED);
}

void generateFruit(LLRoot * master) {
    if(master == NULL) return;

    /* Generation data for fruit between 0-7
     * http://c-faq.com/lib/randrange.html
     */


    sysClock.stop();

    srand (sysClock.read_us());     // Seed random generator
    //sysClock.reset();

    master->fruit_x = (char) (rand() / (RAND_MAX / CUBEDIM + 1));
    master->fruit_y = (char) (rand() / (RAND_MAX / CUBEDIM + 1));
    master->fruit_z = (char) (rand() / (RAND_MAX / CUBEDIM + 1));
    myCube.plotPoint(master->fruit_x, master -> fruit_y, master->fruit_z);
    sysClock.start();
}

void resetSnake(LLRoot * master) {
    if(master == NULL) return;

    if(LLDEBUG) printf("###### GAME RESET; Setting snake back to 0,0,0 ######\r\n\r\n");

    tick.detach();
    freeListLL(master);

    myCube.clearCube();
    initializeSnake(master);


    //sysClock.reset();
    if(LLDEBUG) printListLL(master);

}

void getSnakeInput(void) {
    //LLRoot * master = &Snake;
    char current_dir = Snake.direction;

    /* Determines which button was pressed (out of 6), and prevents
     * the snake from turning in the opposite direction
     * Ex: when going x dir, cannot turn -x
     */
    if(moveFlag) {
        if(b_xpos == 0 && current_dir != XNEG) Snake.direction = XPOS;
        else if(b_xneg == 0 && current_dir != XPOS) Snake.direction = XNEG;
        else if(b_ypos == 0 && current_dir != YNEG) Snake.direction = YPOS;
        else if(b_yneg == 0 && current_dir != YPOS) Snake.direction = YNEG;
        else if(b_zpos == 0 && current_dir != ZNEG) Snake.direction = ZPOS;
        else if(b_zneg == 0 && current_dir != ZPOS) Snake.direction = ZNEG;
        moveFlag = 0;
    }

    // else unknown data condition
}

/* May require the use of a ticker.attach in order to update the snake every
 * x seconds. <http://mbed.org/handbook/Ticker>
 */
void moveSnake(void) {
/*
 * NOTE: This is part of an ISR called by the Ticker
 * So no printf, limited use of malloc.
 * If issues occur, split up function
 */
 /* TODO: test mbed ISR, determine how much memory allocation,
  * max time for ISR, etc
  * REMOVE PRINTF ONCE MIGRATION OCCURS
  */
    LLRoot * master = &Snake;
    LLNode * tmp;
    char sHead_x, sHead_y, sHead_z;
    char apple_x, apple_y, apple_z;
    signed char XDIR, YDIR, ZDIR;
    char count;

    if(master == NULL) return;

    moveFlag = 1;
    errcode = 0;

    /* Careful usage required, stale data can occur with these variables */
    sHead_x = master->head->x;
    sHead_y = master->head->y;
    sHead_z = master->head->z;
    apple_x = master->fruit_x;
    apple_y = master->fruit_y;
    apple_z = master->fruit_z;

    XDIR = YDIR = ZDIR = 0;
    switch(master->direction) {
        case XPOS:
            XDIR = 1;
            break;
        case XNEG:
            XDIR = -1;
            break;
        case YPOS:
            YDIR = 1;
            break;
        case YNEG:
            YDIR = -1;
            break;
        case ZPOS:
            ZDIR = 1;
            break;
        case ZNEG:
            ZDIR = -1;
            break;

        default:
            break;
    }

    /* Update snake nodes */
    __disable_irq();
    addToHeadLL(master, sHead_x + XDIR, sHead_y + YDIR, sHead_z + ZDIR);
    __enable_irq();
    // BEAMMEUPSCOTTY
    myCube.plotPoint(sHead_x + XDIR, sHead_y + YDIR, sHead_z + ZDIR);
    if(LLDEBUG) printf("debug: adding [%d %d %d]\r\n", sHead_x + XDIR, sHead_y + YDIR, sHead_z + ZDIR);

    /* Boundary/Self checking */
    count = 0;
    tmp = master->head;
    while(tmp != NULL) {
        ++count;

        /* Check head coordinates against all other nodes */
        if(count > 1) {
            if((master->head->x == tmp->x) && (master->head->y == tmp->y) && (master->head->z == tmp->z)) {
                if(LLDEBUG) printf("debug: conflict with snake head: [%d %d %d] ... resetting game\r\n", master->head->x, master->head->y, master->head->z);
                resetSnake(master);
                reset = 1;
                errcode = 1;
                break;
            }
        }

        // TODO: flash cube face on wall hit
        // in if statements

        if(tmp->x > BOUNDARY) {
            resetSnake(master);
            reset = 1;
            errcode = 3;
            // TODO: light right wall
            break;
        }
        if(tmp->x < 0) {
            resetSnake(master);
            reset = 1;
            errcode = 3;
            // TODO: light left wall
            break;
        }
        if(tmp->y > BOUNDARY) {
            resetSnake(master);
            reset = 1;
            errcode = 3;
            // TODO: light back wall
            break;
        }
        if(tmp->y < 0) {
            resetSnake(master);
            reset = 1;
            errcode = 3;
            // TODO: light front wall
            break;
        }
        if(tmp->z > BOUNDARY) {
            resetSnake(master);
            reset = 1;
            errcode = 3;
            // TODO: light top wall
            break;
        }
        if(tmp->z < 0) {
            resetSnake(master);
            reset = 1;
            errcode = 3;
            // TODO: light bottom wall
            break;
        }
        tmp = tmp->next;
    }
    //master->length = count - 1;

    if(reset) { reset = 0; return; }

    /* Fruit detection */
    if((sHead_x == apple_x) && (sHead_y == apple_y) && (sHead_z == apple_z)) {
        generateFruit(master);
        errcode = 2;
        if(LLDEBUG) printf("debug: keeping tail [%d %d %d]\r\n", master->tail->x, master->tail->y, master->tail->z);
    }else{
        /* If we detect fruit, there is no need to remove the tail node.
         * Otherwise we can remove it to produce the snake movement
         */
        // BEAMMEUPSCOTTY

        myCube.clearPoint(master->tail->x, master->tail->y, master->tail->z);
        if(LLDEBUG) printf("debug: removing [%d %d %d] because no fruit detected\r\n", master->tail->x, master->tail->y, master->tail->z);
        __disable_irq();
        removeTailLL(master);
        __enable_irq();
    }

    if(LLDEBUG) printListLL(master);       /* Display LL header and node data */
}

void printSnakeCube(const LLRoot * master) {
    int i;

    if(master == NULL) return;

    for(i = 0; i < 8; i++) {
        printf("~~~~~LAYER%d~~~~~\r\n", i);
        printSnakeLayer(master, i);
    }
    printf("ERRCODE: %d\r\n", errcode);
}

void printSnakeLayer(const LLRoot * master, char layer) {
    LLNode * node = master->head;       /* Begin at the head node */
    char board[8][8];
    int x, y;

    if(master == NULL) return;

    for(x = 0; x < 8; ++x)
        for(y = 0; y < 8; ++y)
            board[x][y] = '-';

    if(layer == master->fruit_z)
        board[master->fruit_y][master->fruit_x] = 'x';

    while(node != NULL) {               /* If the node exists, pull the data from it */
        if(node->z == layer) {
            board[node->y][node->x] = 'o';
        }
        node = node->next;
    }

    if(layer == master->head->z)
        board[master->head->y][master->head->x] = 's';

    for(y = 7; y >= 0; --y) {
        for(x = 0; x < 8; ++x) {
            printf("%c", board[y][x]);
        }
        printf("\r\n");
    }

}

/*
    LEDcube.cpp
*/

#include "mbed.h"
#include "LEDCube.h"

LEDcube::LEDcube(I2C &i2c, PinName a, PinName b, PinName c, char deviceAddress, char numChip) : _i2c(i2c), _decode0(a), _decode1(b), _decode2(c){

    _numChips = numChip;
    _baseWrite = deviceAddress & 0xFE;  // low order bit = 0 for write
    _baseRead = deviceAddress | 0x01;   // low order bit = 1 for read

    clearCube();

    _init();
}

void LEDcube::clearCube(){
    int x;
    int y;

    for(x = 0; x < 8; x++)
        for(y = 0; y < 8; y++)
            cubeData[x][y] = 0x00; // Previously 0xff
}

void LEDcube::plotPoint(signed char x, signed char y, signed char z){
    if(x < 0 || x > 7) return; // Ignore bad data, snake function will catch it
    if(y < 0 || y > 7) return; // so we are ok to just return
    if(z < 0 || z > 7) return;
    if(x == 1 && y == 7 && z == 4)
        return;
    cubeData[z][x] = cubeData[z][x] | (0x01 << y);
}
void LEDcube::clearPoint(signed char x, signed char y, signed char z){
    if(x < 0 || x > 7) return;
    if(y < 0 || y > 7) return;
    if(z < 0 || z > 7) return;
    cubeData[z][x] = cubeData[z][x] & ((0x01 << y)^0xff);
}

void LEDcube::drawDiamond(char x, char y, char z, char x2, char y2, char z2){
    if(x > x2 || y > y2 || z > z2)
        return;
    char Xtravel;
    char Ztravel;

    char tempX;

    char xmid = (x2 + x)/2;
    char ymid = (y2 + y)/2;
    char zmid = (z2 + z)/2;

    for(Xtravel = x; Xtravel < x2; Xtravel++){
        tempX = xmid - abs(xmid - Xtravel);
        for(Ztravel = z; Ztravel < z2; Ztravel++){
            if( Ztravel >= (zmid - tempX) && Ztravel <= (zmid + tempX)){
                plotPoint(Xtravel, ymid + tempX - abs(Ztravel - zmid), Ztravel);
                plotPoint(Xtravel, ymid - tempX + abs(Ztravel - zmid), Ztravel);
            }
        }
    }
}

void LEDcube::explodeDiamond(char x, char y, char z){
    clearCube();
    drawDiamond(x - 1, y - 1, z - 1, x + 1, y + 1, z + 1);
    lightCube(CUBE_DELAY);
    ////////////////////
    wait(.3);
    ////////////////////
    clearCube();
    drawDiamond(x - 2, y - 2, z - 2, x + 2, y + 2, z + 2);
    lightCube(CUBE_DELAY);
    clearCube();
    //////////////
    wait(.3);
    /////////////
}

void LEDcube::shiftArray(){
    int x, z;
    char tempArr[8];

    for(z = 0; z < 8; z++)
        tempArr[z] = cubeData[z][7];

    for(x = 7; x < 1; x--){
        for(z = 7; z < 0; z--){
            cubeData[z][x] = cubeData[z][x - 1];
        }
    }
     for(z = 0; z < 8; z++)
        cubeData[z][0] = tempArr[z];
}

void LEDcube::lightLED(int x, int y){
    char chip;
    char port = GPIOB;
    char byte;

    if(x > 7 || x < 0)
        x = 0;
    if(y > 7 || y < 0)
        y = 0;

    byte = ((0x01 << y)^0xff);
    chip = x >> 1;

    if( x % 2 == 1){
        port = GPIOA;
        byte = reverse_byte(byte);
    }

    _write(chip, port, byte);
}

void LEDcube::lightPort(int x, char byte){
    char chip;
    char port = GPIOB;

    if(x > 7 || x < 0)
        x = 0;

    chip = x >> 1;

    if( x % 2 == 1){
        port = GPIOA;
        byte = reverse_byte(byte);
    }
     _write(chip, port, byte);
}

void LEDcube::lightCube(double myWait){
    int layer;
    int x;
    for(layer = 0; layer < 8; layer++){
        _decode0 = layer & 0x01;
        _decode1 = layer & 0x02;
        _decode2 = layer & 0x04;

        // CHANGE LAYER OR SOMETHING
        for(x = 0; x < 8; x++){
           lightPort(x, cubeData[layer][x]);    //A bit faster by removing for loop and using 2nd _write function
        }

        wait(myWait);

        // WAITING
        for(x = 0; x < 8; x++){
           lightPort(x, 0x00); // Previously 0xff
        }
    }
}

void LEDcube::_init() {
    char i, j;

    if(DEBUG) printf("Begin initialization\n\r");
    for(i = 0; i < _numChips; i++){
        _write(i, IOCONA, 0x20); // Set to non-sequential registers
        _write(i, IODIRA, 0x00); // Set Port A as outputs
        _write(i, IODIRB, 0x00); // Set Port B as outputs
    }

    for(i = 0; i < 8; i++)
        for(j = 0; j < 8; j++)
            cubeData[j][i] = 0x00;
}

void LEDcube::_write(char chip, char address, char byte) {
    char data[2];

    data[0] = address;
    data[1] = byte;

    _i2c.write((_baseWrite + (chip << 1)), data, 2);    // Write data to selected Register
    wait(myDELAY);
}

void LEDcube::_write(char chip, char address, char portA, char portB) {
    char data[3];

    data[0] = address;
    data[1] = portA;
    data[2] = portB;

    _i2c.write((_baseWrite + (chip << 1)), data, 3);    // Write data to selected Register
    wait(myDELAY);
}

unsigned char reverse_byte(unsigned char x)
{
    static const unsigned char table[] = {
        0x00, 0x80, 0x40, 0xc0, 0x20, 0xa0, 0x60, 0xe0,
        0x10, 0x90, 0x50, 0xd0, 0x30, 0xb0, 0x70, 0xf0,
        0x08, 0x88, 0x48, 0xc8, 0x28, 0xa8, 0x68, 0xe8,
        0x18, 0x98, 0x58, 0xd8, 0x38, 0xb8, 0x78, 0xf8,
        0x04, 0x84, 0x44, 0xc4, 0x24, 0xa4, 0x64, 0xe4,
        0x14, 0x94, 0x54, 0xd4, 0x34, 0xb4, 0x74, 0xf4,
        0x0c, 0x8c, 0x4c, 0xcc, 0x2c, 0xac, 0x6c, 0xec,
        0x1c, 0x9c, 0x5c, 0xdc, 0x3c, 0xbc, 0x7c, 0xfc,
        0x02, 0x82, 0x42, 0xc2, 0x22, 0xa2, 0x62, 0xe2,
        0x12, 0x92, 0x52, 0xd2, 0x32, 0xb2, 0x72, 0xf2,
        0x0a, 0x8a, 0x4a, 0xca, 0x2a, 0xaa, 0x6a, 0xea,
        0x1a, 0x9a, 0x5a, 0xda, 0x3a, 0xba, 0x7a, 0xfa,
        0x06, 0x86, 0x46, 0xc6, 0x26, 0xa6, 0x66, 0xe6,
        0x16, 0x96, 0x56, 0xd6, 0x36, 0xb6, 0x76, 0xf6,
        0x0e, 0x8e, 0x4e, 0xce, 0x2e, 0xae, 0x6e, 0xee,
        0x1e, 0x9e, 0x5e, 0xde, 0x3e, 0xbe, 0x7e, 0xfe,
        0x01, 0x81, 0x41, 0xc1, 0x21, 0xa1, 0x61, 0xe1,
        0x11, 0x91, 0x51, 0xd1, 0x31, 0xb1, 0x71, 0xf1,
        0x09, 0x89, 0x49, 0xc9, 0x29, 0xa9, 0x69, 0xe9,
        0x19, 0x99, 0x59, 0xd9, 0x39, 0xb9, 0x79, 0xf9,
        0x05, 0x85, 0x45, 0xc5, 0x25, 0xa5, 0x65, 0xe5,
        0x15, 0x95, 0x55, 0xd5, 0x35, 0xb5, 0x75, 0xf5,
        0x0d, 0x8d, 0x4d, 0xcd, 0x2d, 0xad, 0x6d, 0xed,
        0x1d, 0x9d, 0x5d, 0xdd, 0x3d, 0xbd, 0x7d, 0xfd,
        0x03, 0x83, 0x43, 0xc3, 0x23, 0xa3, 0x63, 0xe3,
        0x13, 0x93, 0x53, 0xd3, 0x33, 0xb3, 0x73, 0xf3,
        0x0b, 0x8b, 0x4b, 0xcb, 0x2b, 0xab, 0x6b, 0xeb,
        0x1b, 0x9b, 0x5b, 0xdb, 0x3b, 0xbb, 0x7b, 0xfb,
        0x07, 0x87, 0x47, 0xc7, 0x27, 0xa7, 0x67, 0xe7,
        0x17, 0x97, 0x57, 0xd7, 0x37, 0xb7, 0x77, 0xf7,
        0x0f, 0x8f, 0x4f, 0xcf, 0x2f, 0xaf, 0x6f, 0xef,
        0x1f, 0x9f, 0x5f, 0xdf, 0x3f, 0xbf, 0x7f, 0xff,
    };
    return table[x];
}
